Reflow

Design your own PCB and learn reflow soldering!

Design a PCB
Design a PCB
Use KiCad (or your favorite EDA) to design a PCB using SMD components
Get a Hotplate
Get a Hotplate
Get a hotplate, solder paste, and a testing PCB to practice on
Get a Grant
Get a Grant
Get a grant to order the PCB you designed, and parts to reflow solder on it!

What is Reflow?

Reflow is a limited-time You Ship, We Ship (YSWS) where you first design your own PCB using SMD components (Surface Mount Devices). Once your design is complete, you receive a PCB, parts, and tools to practice reflow soldering. Afterward, you get a grant to have your design professionally fabricated and another grant to purchase the necessary components!

Requirements

Here are some rules your design should follow!

  • You must document your progress and post scraps in the appropriate Slack channels
  • You must track time using Hackatime
  • At least 80% of the components in your design should require SMD soldering
  • You must NOT rely on external assembly serivces
  • Your design should pass automated review: see docs
  • Your design must be original

    • FAQ

    If you have any other questions, please ask in the #reflow channel!
